HEATSAIL · OUTDOOR LIVING
Heatsail DOME Bow Bracket Wall Mounted Patio Heater & Light
The Heatsail Dome Bow Bracket is an elegant wall-mounted solution that brings the signature warmth and lighting of the Heatsail Dome to outdoor spaces where floor space is at a premium. This wall-bracket design features the same award-winning functionality as the freestanding Dome, delivering far-infrared heat and adjustable LED lighting with a graceful arched bracket that extends from the wall. Perfect for patios, balconies, and terraces, the Dome Bow Bracket creates a sophisticated focal point while maximizing usable floor space.
Available in Midnight or Snow, with custom RAL colours available for a personalized touch, the Heatsail Dome Bow Bracket blends seamlessly into any outdoor setting. Made from high-quality marine-grade stainless steel and powder-coated aluminum, it ensures long-lasting durability and performance in all weather conditions. The energy-efficient far-infrared heating system provides comfortable warmth without emitting harmful CO2, while the integrated LED lighting with golden interior creates a warm, inviting ambiance. Control both heating and lighting through the included wall switch with dimmer, allowing you to adjust your outdoor environment effortlessly.
Product Details & Advice
Additional product information
• 1 × Heatsail Dome with Hood (100 cm diameter)
• 1 × Bow Bracket (55 × 14 × 1 cm)
• 1 × Integrated LED light (120W) with golden interior
• 1 × Far-infrared heating element (3100W)
• 1 × Wall switch with dimmer and separate heat/light controls
• All mounting hardware included
• IP43 weather-resistant rating
Colour Options
Midnight (RAL 9005)
Snow (RAL 9003)
Key Features
- Space-Saving Wall Mount: Elegant arched bow bracket extends gracefully from the wall, freeing up floor space while providing overhead heating and ambient lighting for patios and terraces.
- Dual Heat Settings: Two adjustable heat levels deliver up to 3100W of far-infrared warmth, covering 12-16 m² with energy-efficient comfort.
- HT+ Technology: Advanced Heattube+ system generates up to 25% more heat with the same power consumption, maximizing efficiency and reducing energy costs.
- Golden Interior Lighting: Integrated 120W dimmable LED with golden reflective interior creates a warm, luxurious glow perfect for evening entertaining.
- Independent Controls: Wall switch allows separate control of heating and lighting functions, with dimmer for precise ambiance adjustment.
- Weather-Resistant Construction: Marine-grade stainless steel and powder-coated aluminum with IP43 rating ensure rust-free, year-round durability in all weather conditions.
- Zero Emissions: Far-infrared technology provides instant, comfortable warmth without gas, harmful CO2 emissions, or open flames.
- Low Maintenance: High-quality materials are virtually maintenance-free, with ceramic heating elements designed for long-lasting performance.
Dimensions
| Component | Measurement |
|---|---|
| Hood Diameter | 100 cm (3' 3.4") |
| Hood Height | 38 cm (1' 0.6") |
| Bow Bracket | 55 × 14 × 1 cm (9.6" × 5.5" × 0.4") |
| Total Width (with bracket) | 207 cm (6' 9.5") |
| Total Height | 235 cm (7' 8.5") |
| Mounting Height Requirement | Min: 180 cm (5' 11") | Max: 195 cm (6' 4.8") from ground |
| Weight | Approximately 26 kg (56 lbs) |
Technical Specifications
| Specification | Details |
|---|---|
| Power Consumption | 3.22 kWh |
| Heat Output | 3100 Watt (two settings: low & high) |
| Light Output | 120 Watt (dimmable LED with golden interior) |
| Heating Coverage | 12-16 m² (estimated) |
| Voltage | 230V |
| IP Rating | IP43 (weather-resistant) |
| Control System | Wall switch with dimmer and separate heat/light controls |
| Materials | Marine-grade stainless steel and powder-coated aluminum |
| Certifications | CE, IEC approved |
Why Choose Heatsail?
Care & Warranty
Heatsail Warranty
Product Questions
How do I choose the right configuration?
Choose from the options shown above. For help with finishes, mounting or installation requirements for the Heatsail DOME Bow Bracket Wall Mounted Patio Heater & Light, call 01277 812777 before ordering.
Where can I find the specifications?
Open Additional product information for the listed dimensions, technical details and configuration information. Follow the manufacturer’s installation instructions for your chosen model.
Product Data Sheet
Plan Your Outdoor Space
Call 01277 812777 for help choosing your Heatsail product and configuration.
